Full-tooth tungsten steel spiral milling cutter has flexible and wide range of processing applications. Milling and trimming can be completed at one time, saving processing time.
| 5 VUA 01050303TX | 1.05 | 0.3 | M1.4 x 0.3 | 2.8 | 3T | 4 | 50 | |
| 5 VUA 01200353TX | 1.2 | 0.35 | M1.6 x 0.35 | 3.2 | 3T | 4 | 50 | |
| 5 VUA 01550403TX | 1.55 | 0.4 | M2 x 0.4 | 4 | 3T | 4 | 50 | |
| 5 VUA 01950453TX | 1.95 | 0.45 | M2.5 x 0.45 | 5 | 3T | 4 | 50 | |
| 5 VUA 02300503TX | 2.3 | 0.5 | M3 x 0.5 | 6 | 3T | 6 | 50 | |
| 5 VUA 03200703TX | 3.2 | 0.7 | M4 x 07 | 8 | 3T | 6 | 60 | |
| 5 VUA 04000803TX | 4 | 0.8 | M5 x 0.8 | 10 | 3T | 6 | 60 | |
| 5 VUA 04801003TX | 4.8 | 1.0 | M6 x 1.0 | 12 | 3T | 6 | 75 | |
| Model No. | Diameter D | Pitch | Thread | Effective Length DL | Flute T | Shank Diameter d | Overall Length L | price |
|---|
Remarks: For other specifications, please call to inquire
